1064nm 1W Pulse Laser
Amonics offers Pulse Laser at 1064nm with high pulse peak power. The laser features tunable pulse width from 10ns to 1us and no short pulse driving source is required. It is ideal for applications demanding laser emission with high pulse peak power.
The turnkey microprocessor controlled Pulse Laser comes in both benchtop and rackmount casings. It is equipped with alarms and status indicators. An integrated RS232 computer interface provides easy control, diagnostic functions and data acquisition. Available options include single frequency operation and linearly polarized operation.
Specifications
| APLS-1064-01 | |
|---|---|
| Pulse Peak Power | Min. 700 mW, Typ. 1 W |
| Center Wavelength | 1064 nm |
| Pulse Width | 5 ns to 100 ns (duty cycle < 2 %, repetition rate < 500 kHz) |
| On/Off Extinction ratio | Min. 25 dB |
| Trigger voltage | TTL (standard) |
Other wavelength or output power models are available upon request.
General Parameters
| unit | value | remarks | |
|---|---|---|---|
| Operation Temperature | °C | 0 to +40 | |
| Storage Temperature | °C | -10 to +70 | |
| Power Supply | VAC | 90 – 240, 47 – 63Hz | |
| Benchtop Dimensions | mm | 260(W) x 330(D) x 120(H) | |
| 1U Rackmount Dimensions | mm | 485(W) x 360(D) x 45(H) | Other standard rackmount sizes are also available |
| Mechanical Safety Control | Key-lock switch, BNC interlock key | ||
| Optical Power Monitoring | Output power | ||
| Remote Control Port | DB-9 female (RS232), Control software included, RJ-45 (TCP/IP Ethernet) (optional) | ||
| RF Port | SMA or BNC | ||
| Protection | Pump laser (TEC) overheat | ||
| Optical Connector | FC/APC, FC/UPC, SC/APC, SC/UPC | ||
| Optical Fiber | Hi-1060 / PM 980 |
Options
| Linear polarized |
Ordering Information
| Product Code |
|---|
| APLS-aaaa-bb-c-dd |
| aaaa: Wavelength in nm |
| bb: Output power in W |
| c: B for Benchtop, R for 19” Rackmount |
| dd: FA for FC/APC, FC for FC/UPC, SA for SC/APC, SC for SC/UPC |
Key Features
| Turnkey device |
| RS232 computer interface |
| High output power |
| Single mode fiber delivery |
| Highly reliability and durable |
