High Power 1064nm Narrow Linewidth Fiber Laser
Amonics' high power 1064 nm narrow linewidth fiber lasers are with very narrow linewidth, high power stability, and low RIN noise. The standard model of 1064 nm narrow linewidth fiber laser delivers up to 2 Watt output, with linewidth < 15 kHz and RIN noise < -135 dB/Hz for frequency below 100 kHz. Other linewidths can be customized according to customers requests. The applications of the narrow linewidth laser include free spacing sensing, 532 nm second harmonic laser generation, and experiments in nonlinear fiber optic.
Specifications
| AULLD series | |
|---|---|
| Laser Wavelength | 1062 to 1066 nm, CW @ rated power |
| Optical Output Power | 13 dBm, 17 dBm, 20 dBm, 23 dBm, 27 dBm, 30 dBm, 33 dBm |
| Linewidth FWHM, Lorentzian | Max. 15 kHz CW @rated power |
| Optical Isolation | Min. 25 dB, under operation temp. |
| Side-mode Suppression Ratio | Min. 35 dB, Typ. 45, CW @rated power |
| Relative Intensity Noise | Shot noise limited @ frequency Min. 100 kHz |
| Output Power Stability | Max. +0.2 dB (within 8 hrs), Max. +0.03 dB (within 10 mins) CW @ rated power and constant environment temperature |
| Wavelength Stability | Max. +0.005 nm (within 8 hrs), Max. +0.001nm (within 10 mins) CW @rated power and constant environment temperature |
General Parameters
| unit | value | |
|---|---|---|
| Operation Temperature | °C | 0 to +40 |
| Storage Temperature | °C | -10 to +70 |
| Power Supply | VDC | +12V ± 0.25V |
| Module Dimensions | mm | 300(W) x 250(D) x 70(H) |
| Optical Power Monitoring | Output power | |
| Remote Control Port | DB-9 female (RS232) | |
| Protection | Pump laser (TEC) overheat | |
| Optical Connector | FC/APC, FC/UPC, SC/APC, SC/UPC, bare fiber | |
| Optical Fiber | PM 980, Hi-1060 (optional) |
Ordering Information
| Product Code |
|---|
| AULLD-aa-bbbb-cc-dd-M-ee |
| aa: Default (or unspecified) for single mode, PM for polarization maintaining |
| bbbb: Wavelength in nm |
| cc: Laser linewidth in kHz |
| dd: Output power in dBm |
| ee: FA for FC/APC, FC for FC/UPC, CL for collimator, SA for SC/APC, SC for SC/UPC, NC for bare fiber |
Applications
Key Features
| Narrow linewidth |
| Low phase noise |
| Ultra low RIN |
| High output power, up to 2W |
| RS232 remote control |
| Ultra stable |
| Linear polarized output (Option) |
| Wavelength tunability (Option) |
